Custom Stainless Steel Lateral Tee and Y-Branch Fitting
This welded pipe fitting combines a straight main run with an angled reducing branch. It can be produced as a 30°, 45° or 60° lateral tee from an approved drawing for piping, ducting and fabricated equipment connections.
Reference Specifications
| Product type | Welded lateral tee / Y-branch / reducing branch pipe fitting. |
|---|---|
| Reference materials | 304 and 316 stainless steel are listed in the supplied supplier reference. |
| Custom materials | Other stainless steel grades, carbon steel, aluminum alloy, nickel alloys and special alloys can be evaluated against the drawing and service requirements. |
| Branch angles | Reference options include 30°, 45° and 60°. |
| Reference sizes | DN25, DN50, DN60, DN80 and DN100 are shown as supplier options. Main and branch diameters may differ. |
| End type | Plain weld ends shown. Bevel preparation, wall thickness and end dimensions to be specified. |
| Manufacturing | Formed and welded construction; exact forming and weld procedure depend on material, diameter and wall thickness. |
| Standard | Drawing-based/custom unless a governing piping specification is stated on the order. |
Ordering Information
Provide the main-pipe and branch outside diameters, wall thicknesses, branch angle, centerline dimensions, material grade, end preparation, quantity and delivery destination. State the design pressure, temperature, medium, inspection and certification requirements so suitability can be reviewed.
The supplied photographs show the fitting form only and do not establish a pressure rating or piping-code compliance. Final dimensions and acceptance criteria should follow the approved drawing.
